工业等级平板显示器

TPC-318WH

搭载Intel®core™ 8th i5 处理器通过 UL Class 1 Division 2 认证的防爆型工业平板电脑

  • 工业级 18.5 " WXGA TFT LCD 显示屏，背光寿命 50K，配备 LED 背光
  • Intel®core™ 8th i5-8365UE 四核处理器，内置 8 GB DDR4 SO-DIMM
  • 双通道内存插槽最大支持64G
  • 紧凑、无风扇嵌入式设计，带有铝合金前挡板和底盘接地保护
  • 配备 PCAP 触摸控制和 IP66 级前面板的纯平触摸屏
  • 支持全尺寸 Mini PCIe 和两个 M.2 插槽 (NVMe、5G) 进行扩展
  • 支持TPM2.0硬件安全

认证：

技术资源链接：

产品型录 Download 3D Model 技术文件下载
  • 搭载Intel®core™ 8th i5 处理器通过 UL Class 1 Division 2 认证的防爆型工业平板电脑

规格

LCD Display
Display Size
  • 18.5"
Luminance (cd/m2)
  • 450
Max. Resolution
  • 1366 x 768
Power Supply
Input Voltage
  • 12~24 VDC
Touchscreen
Touch Type
  • 10-point multi-touch projected capacitive
Hardware
CPU
  • 8th Gen. Intel® Core™ i5-8365UE 1.60GHz Quad-Core
Memory
  • 1 x SO-DIMM Memory with 8 GB DDR4 3200 MHz
Storage
  • 1 x SATA M.2 SSD slot (2280 M-Key)
    ;
    1 x 2.5" SSD/HDD Bay, 1 x mSATA, 1 x M.2 B key
I/O Interface
LAN Ports
  • 2 x 10/100/1000 Mbps
USB Ports
  • 4 x USB 3.2
Serial Ports
  • 2 x RS 232/422/485
Displays
  • 1 x DP
Audio
  • Line-Out, Mic-In
USB Vision
Connector
  • 1 x USB 2.0 Type A
Expansion Function
Interface
  • 1 x Full-size mini PCIe
Mechanical
Mounting
  • Panel, Wall, Stand, VESA

特点和优势

Why the Prevention of Exposures is Necessary?

The presence of explosive substances like gas, liquid forms, or dust is not unusual. These substances can be an invisible danger that people are often unaware of. Factory requires reliable data preservation and electrical safety. By adopting explosion-proof certified equipment, important data assets and workers alike can be assured a safe environment.

C1D2-HMI-Industrial Panel-Adcantech

The Class I, Division 2 (C1D2) safety certification is an OSHA-mandated requirement for devices. A C1D2 hazardous location is defined as an area where flammable liquids, gases, or vapors may accidentally exist in sufficient quantities to produce an explosion or fire.

TPC-318WH Technical Advantages

Advantech TPC-318WH High Performance with Intel Core processor and Windows support

High Performance

  • Intel® Core™ i5 8365UE processor
  • 8GB DDR4 SODIMM (built-in, up to 32GB) storage
  • Supports Windows 11 and Linux
Advantech TPC-318WH Industrial-Grade Design with IP66 protection and -20°C to 60°C operation

Industrial-Grade Design

  • IP66-rated front panel
  • C1D2 certification
  • Wide operating temperature range


Advantech TPC-318WH Security Features with TPM 2.0 and hardware-based protection

Enhanced Data Security

  • Built in TPM 2.0
  • Provides hardware-based security
Advantech TPC-318WH Display with 18.5-inch full HD and multi-touch capabilities

Superior Visual Quality

  • 18.5” full HD true flat display
  • Multi-touch PCAP control
  • Provides more detailed imaging and convenient operation

Many industries have environments

with explosion hazards

Industry with explosion hazards-HMI-Oil&Gas
Case Study-Industrial HMI-Advantech HMI

Case Study

Download Now

About Explosion-Proof Certification Equipment

  • Edge Data Collection in Hazardous Industrial
  • System Integrator for petrol stations
  • Vibration Sensor in Oil Refiner
  • Monitoring Solutions for Gas Stations
